LKAD016D-C 15W 20-45V 350mA Linear Lamp 0-10V dimming  led driver

Features

• 200-240Vacc(50/60Hz) Input
• Hight efficiency,hight PF,good steady;
• Isolated,0-10V dimming ,adjusting much smoothly

• independent, ClassⅡconstant current type;
• short circuit/over load/over current/ over temperature protection;
• 100% full load burn-in test;
• degree of protection IP20;
• Special for LED linear lamp, LED grille lamp;
• 5 years warranty.

---

More Details

Model		LKAD016D-C
輸入 Input	輸入電壓范圍/Input Voltage ra	120-277V
	頻率/Frequency	50/60hz
	諧波/THD	≤10%
	功率因數/Power factor	0.95/240VAC
	輸入電流 Input current（mA)	80MA/240V
	待機功耗 stand_by power	≦1W
	浪涌電流 Inrush Current(Max.)	≤40A@240VAC
	漏電流 Leakage Current	<1MA/240V
輸出 Output	額定電壓/Rated voltage	45V
	空載電壓/No-load Voltage	≦49V
	工作電壓范圍/working voltage	0-45V
	可選擇電流規格/selectable cur	r                  350MA±10MA
	電流精度/Current precision	(+/-)3%
	額定功率/Rated power	35W
	開機延時/Setup Time	≤0.5s/230VAC
	輸出線性調整率Output Line Reg	u                      ±5%
	溫度漂移temperature drift	±10% Page 1 of 4
