Model

LKAD060P

輸入Input

AC電壓范圍/AC Voltage range

90-277V

頻率/Frequency

50/60Hz

諧波/THD

功率因數/Power factor

0.93/230VAC

輸出Output

額定電壓/Rated voltage

42V

空載電壓/No-load Voltage

45

DC電壓范圍/DC voltage range

25-42V

DC電流范圍/DC current range

1120-1250mA

電流精度/Current precision

(+/-)5%

額定功率/Rated power

50W

開機延時/Setup Time

≤0.5s/230VAC

使用環境Environment Requirements

工作溫度/濕度要求Operating Temp./RH

-30～+45℃/20～95%

儲存溫度,濕度要求

Storage Temp./RH

-40～+80℃/10～95%

安全和電磁兼容

認證標識/Certificate

UL:E475760

FCC:EM201500163-1

SAA:SF201501543

CCC:2016011002845332

其他

尺寸/Size

L125+16mm*W52mm*H33mm

重量/Net weight
